4- TECHNICAL FEATURES
DTS Product codes:
03.MS014.EBLFP MAX FPR Black finishing
Lamp
Philips MSD PLATINUM 16R 330W (16.000 Lumens)
Color temperature: 8000K
Remote lamp On-Off
Average lamp life: 1.500 hours
Optical group
Improved optical group made with 11 coated lenses
100.000 Lux at 5 m
16-bit motorized wide-excursion linear zoom
Beam opening:
2° - 37° (Beam-Spot mode)
10° - 60° (Wash projection)
16-bit motorized linear focus
Motorized Iris
Linear dimmer / shutter / strobe (0,85 flash/sec to 10 flash/sec)
Frost filter
Colour generation
Linear CMY + CTO
Color wheel (17 colors) with linear selection for perfect 2-color beams
Dynamic effects
Overlapping wheels for multiple effects:
Customizable rotating gobo wheel (8 gobos + Open Studio)
Customizable fixed gobo wheel (10 gobos)
Animation Wheel
4-facet rotating prism
Interface / Control / Programming
Li-Fe backup battery for controlling the main parameters even when MAX is not
powered
LCD graphic display + 4 soft-keys (control / management / monitoring of the main
parameters)
Controlled via DMX 512 and RDM standard digital communication protocols
Internal operating system updatable via DTS Dongle Firmware Uploader
DMX
33 DMX channels (Default) or 24 DMX channels
