DTS 03.MS014.EBLFP User Manual

39
19- DMX PROTOCOL
24 CHANNELS MODE
1 PAN msb
2 PAN lsb
3 TILT msb
4 TILT lsb
5 SPEED MOVEMENT
6 FPR MODE
7 DIMMER
8 SHUTTER
9 COLOUR
10 CYAN
11 MAGENTA
12 YELLOW
13 CTO
14 GOBO
15 GOBO ROTATION / INDEX
16 FIXED GOBO
17 IRIS
18 ANIMATION
19 FROST
20 PRISM
21 PRISM / ANIMATION ROTATION
22 FOCUS
23 ZOOM
24 RESET + LAMP
DMX CHANNEL
1
Parameter: PAN msb
DMX CHANNEL
2
Parameter: PAN lsb
DMX CHANNEL
3
Parameter: TILT msb
DMX CHANNEL
4
Parameter: TILT lsb
DMX CHANNEL
5
Parameter: SPEED MOVEMENT
DMX value
Function
000-010
Standard
011-025
Fast movement
026-127
Vector mode from fast to slow
128-247
Variable time reaction to dmx signal (fast to slow)
248-255
Silent movement
