DTS 500 - Page 16

16
Screwing the horizontal fin mount can
keep the horizontal fin remaining in
horizontal position.
Two tail boom support
ends are 90 degree
angle to each other.
Install the tail boom support end A to the
main frame, end B to the horizontal fin
mount. Then, install the horizontal fin
by using the fin mount.
Fix the commpleted tail boom to the main
frame. Make sure that the geat sets rotate
smoothly.
Install the servo to tail servo support cross
member. (According to left diagram)
120
2pcs
1pcs
1pcs
1pcs
2pcs
2pcs
2pcs
ST3*12
Hexagon Socket
Head Screw
Horizontal Fin
Upper Horizontal
Fin Mount
Lower Horizontal
Fin Mount
090
4*280
Tail Boom Support
End B, Straight
Tail Boom Support Rod
Tail Boom Support
End A, Straight
066
089
088
083
067
068
083
037
088
089
003
090
ST3*10
Spacer
2pcs
003
037
4pcs
Hexagon Socket
Head Screw
ST3*10
068
067
037
066
ST3*16
Hexagon Socket
Head Screw
10pcs
065
065
ST3*10
Hexagon Socket
Head Screw
086
120
037
2pcs
4pcs
037
Spacer
086
Servo
1pcs
297mm
Apply amount
of T43 thread-
locking fiuld
Apply little am-
ount lubricants
No
Description
Qty
need
Specification
No
Description
Qty
need
Specification
No
Description
Qty
need
Specification
