10
7.3) HOLIDAY LOCK OUT ON/OFF.
7.3.1) Press and hold SET (K1) until the LED display setting number 4, release SET (K1). It is now in holiday lock out
program.
7.3.2) Press UP (K3), LED display 1, holiday lock out is now activated or press DOWN (K4) , LED displays 0, holiday lock
out is now de-activated.
7.3.3) Press SET (K1) to store your settings.
7.3.4) The GDO will allow one opening and closing. After closing, allow 2 seconds for lock out to activate.
Note: When the GDO is in lock out mode, the DTS 60TX4 is the only transmitter that can be used to open the GDO. First press
the button with the lock printed on the button followed by, within 2 seconds, the button that is programmed into the
receiver.
Self Learning Transmitter. (Maximum 20)
8.1) Press CODE (K2), the Red dot will light up.
Press and release a button on the transmitter, the Red dot will disappear, press the same button again, the Red dot will flash
and then be replaced by a II on the LED display. Transmitter is programmed successful.
8.2) Repeat step 1 to code a maximum of 20 transmitters onto the DTS600/800 operator.
8.3) To master erase the DTS600/800 receiver, press and hold CODE (K2), the LED display dot will flash, keep holding for
approximately 8 seconds until the LED display flashes a C. Release button. All transmitters are now deleted.
Note: The DTS 60TX4 transmitter button with the lock printed on it CANNOT be programmed into the receiver.
Maintenance.
No particular maintenance is required for the logic circuit board. Check at least twice a year that the door is properly balanced
and that all working parts are in good working condition.
IMPORTANT: A poorly operating door can affect the life of the automatic operator due to incorrect loads and will void the
warranty. Make sure that the safety devices are working effectively (photo beams, etc.). Check the reversing sensitivity at
least twice a year and adjust if necessary.
Final Notes.
This manual is only for the use of technical personnel qualified to carry out the installation. No information given in this
manual can be considered of any interest to the end user. No setting or adjustments contained in this manual can be carried
out by the end user.
It is important for the installer to show their clients correct operational use of the DTS600/800 operator, including the use of the
manual disengagement cord. Inform the owner about the need for a regular and accurate maintenance, especially regarding a
regular check of the safety and reversing devices.
Technical Specifications.
Power Input 220VAC 50Hz Motor 24VDC 100W
Courtesy light time 3 minutes Working temperature -29 degrees to +70 degrees C
Relative Humidity < 90 % Open and close force 600 N
Reception frequency 433.92 MHz Decoding Rolling code
Transmitter power 12V Battery Globe 220V 25 watt screw type
Sensitivity > 1 V for correct receiver signal (average range 50 Meters, with an aerial)
NOTE: DTS Security Products reserves the right to modify its product and product specifications at any time
without prior notice.
