9- PAN & TILT SPEED (SPEE) (default: 4)
10- FAN SPEED (FANS)( default: 12)
You can set the PAN and TILT motors at high speed on your Xr5.
Press menu until you see SPEE.
Press ENTER and select a speed with UP-DOWN (there are 4 speeds). Confirm by pressing ENTER.
When you use speed 4 (the highest) PAN and TILT speed is very high and your projector may loose its
path. In this case, the encoder corrects the position.
Fan speed regulation makes it possible to reduce fan noise. However, the ambient temperature must be
less than 35° C.
11- ERROR MESSAGES:
14
ERROR ENCODER PAN
ERROR ENCODER TILT
ERROR DMX ADDRESS
ERROR LOADING
ERROR COLOUR SENSOR
ERROR COLOUR SENSOR
EPROM DATA
CIRCUIT/ZOOM 1
CIRCUIT/ZOOM 2
ERROR POSITIONING
ERROR ALIGNMENT
ERROR INTERNAL
ERROR INPUT
ERROR POSITIONING
OF COLOUR WHEEL
ERROR POSITIONING
OF BEAM SHAPE EFFECTS
OF ZOOM
SENSORS OF ZOOM LENS
IN AUTO MODE
COMMUNICATION
ERROR SYNCHRONIZED
FREQUENCY MEASURE
(SYNCHRONISM FOR LAMP ON)
ARC 1200
XR 5 WASH
