DTS XR 5 WASH User Manual

16- DMX PROTOCOL
17
16 CHANNEL MODE ( 16bit)
1 PAN ms b ( 5 4 0°)
2
3
TILT msb(320°)
4 TILT l s b
5
6 D IM MER
7 SHU T T ER
8 C OL OUR
9 C YAN
10 MAGENTA
11 YEL L O W
12 SPEED CMY / DIMMER
13 MACRO CMY / COLOUR
14 E FF ECTS
15 ZOOM
16 RESET
DMX CHANNEL
1
Parameter:
PAN msb 540°
DMX CHANNEL
2
Parameter:
PAN lsb
DMX CHANNEL
3
Parameter:
TILT msb 319°
DMX CHANNEL
4
Parameter:
TILT lsb
DMX CHANNEL
5
Parameter:
MOVEMENT SPEED
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-10 Standard
11-25 Fast movement
26-127 Vector mode from fast to slow
128-247 Variable time reaction to
DMX signal ( fast to slow)
248-255 Slow reaction time to DMX
signal
DMX CHANNEL
6
Parameter:
DIMMER
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-8 Black-out
9-255 Proportional dimmer
PAN lsb
MOVEMENT SPEED
ARC 1200
XR 5 WASH
