DTS XR 5 WASH User Manual

-
21
DMX CHANNEL
14
Parameter:
EFFECTS
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-19 No effect
20-39 Frost
40-255 Beam Shape
DMX CHANNEL
15
Parameter:
ZOOM
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-225 Proportional
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-29 No effect
30-85
Lamp OFF (active after 3
seconds)
86 - 170 Internal motor Reset
171-235 Total Reset
236-255
Lamp ON (active after 3
seconds)
DMX CHANNEL
16
Parameter: LAMP / RESET
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-9
10-60
61-129
130-179
180-200
201-239
240-255
No Effect
Lamp OFF (Active after 3 seconds)
No Effect
Internal Motors Reset
Total Reset
Lamp ON (Active after 3 seconds)
No Effect
5
30
95
154
190
220
247
MODE 1 (DEFAULT)
MODE 2 (SAME AS XR 250 WASH)
ARC 1200
XR 5 WASH
