7.1-DMX Addresses

XR 5 Wash have 16 DMX channels.

Set the following addresses on the mixer:

Projector 1 A001

Projector 2 A017 If you want to select the next projector, just add “16”

Projector 3 A033

….. A….

projector 6 A081

7.2-Selecting the DMX address

1) Press the UP-DOWN key until you reach the required DMX channel. The numbers on the display will

start to flash (but the new DMX address hasn't yet been set).

2) Press ENTER to confirm your selection. The numbers on the display will stop flashing and the

projector is now setted to the new DMX address.

TRICKS:

if you keep pushed the UP or DOWN keys, the channels are calculated more quickly and you get a

faster selection.
