Dual CS 329 User Manual

13
Motor
Drive
Belt / DC Motor
Speed settings
33/45
Wow & Flutter
< ±0,12 % (DIN WTD)
Tonearm
Function
Fully automatic or manually operated
Bearing
Ball-bearing
Effective length
221,5 mm
Offset Angle
25,6°
Overhang
19 mm
Type
statically balanced, fixed setting
Stylus Pressure Range
1,8 g +/- 0,3 g
Factory installed Pick-up
Audio-Technica AT91
Replacement Stylus
Audio-Technica ATN91
Platter
Material
Aluminium Die-cast
Mat
Rubber 2,5 mm
Bearing
Hardened Steel Spindle, Brass Bushing
Diameter
296 mm
Weight incl. Mat
667 g
Plinth
Surface Finish
Plastic / MDF Construction
Feet
Ø 62 mm / Elastomer Damping Element
Connection
RCA cable, fixed
Connection to Phono Input
YES
Connection to Line Input
YES
Digital Output
X
Dimension (closed dust cover)
435 x 372 x 132 mm
Dimension (open dust cover)
T: 405 mm / H: 390 mm
Weight
5 kg
Power Supply
The efficiency readings were taken with an input Voltage
of 230 V AC at 50 Hz
Type
FJ-SW 1261200500DN
Input Voltage
100 (-10 %) V AC to 240 (+10 %) V AC
Frequency
50 / 60 Hz
Output Voltage
12 V DC
Output Current
0,5 A
Output Watt
6 W
Average Efficiency During Operation
≥ 78.88%
Power Consumption at Idle
< 0,1 W
Technical Specifications
