Dual DV605 - Page 14

13
AM/FM/RDS Tuner Operation
DV605 OPERATION
Press to adjust the following Audio options:
• EQ - Select from the preset EQ options: JAZZ, CLASSIC, POP,
ROCK, BEAT OR FLAT, or select USER to manually adjust Bass,
Middle and Treble options between -7 and 7.
• Fader/Balance - Drag to adjust Fader options between 10F (front)
and 10R (rear) and Balance options between 10L (left) and 10R
(right).
• Subwoofer/Loudness
- Adjust subwoofer volume from 1-12, or turn subwoofer OFF.
- Select between OFF, LOW or HIGH loudness levels.
• ASP
- Bass Center Frequency: 60Hz, 80Hz, 100Hz or 200Hz.
- Bass Q Value: 1.0, 1.25, 1.5 or 2.0.
- Middle Center Frequency: 500Hz, 1 kHz, 1.5kHz or 2.5kHz.
- Middle Q Value: 0.5, 0.75, 1.0 or 1.25.
- Treble Center Frequency: 10kHz, 12.5kHz, 15kHz, 17.5kHz.
- Loudness Center Frequency: FLAT, 400Hz, 800Hz, 2400Hz.
- Subwoofer Center Frequency: FLAT, 80Hz, 120Hz, 160Hz.
Audio
10
13
11
12
10
