Dual DXDM280BT - Installation Preparation; Pre-Installation Checks; Installation Step-by-Step

2
DXDM280BT INSTALLATION
Decorative
Bezel
Preparation
Please read entire manual before installation.
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for instructions.
• Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
• Remove trim ring from unit.
• Remove 2 transit screws located on top of the unit.
• Connect wiring harness and antenna. Consult a qualified technician if you are unsure.
• Certain vehicles may require an installation kit and/or wiring harness adapter (sold
separately).
• Test for correct operation.
• Snap trim ring into place.
TYPICAL FRONT-LOAD DIN
MOUNTING METHOD
