DUC Hélices FLASH-R - Impact Location on the Blade Carbon Surface

22/27
Impact location on the blade carbon surface 7.5.
If there is any doubt about the blade surface, contact the DUC Hélices company.
« Blade tip» area
(20 cm from the tip of the blade)
Significant impact:
- Depth: from 1mm
- Surface: from 5mm²
Low impact:
- Depth: less 1mm
- Surface: less 5mm²
Significant impact:
- Depth: from 1mm
- Surface: from 2mm²
Low impact:
- Depth: less 1mm
- Surface: less 2mm²
« Blade root » area
(From blade root to 20 cm from the tip of the blade)
