Mototelaio
Frame
sezione / section
H 2
5
A
B
C
D
E
F
G
H
L
M
N
P
Monster 400/620 - M.Y. 2004 - edizione/edition 00
2 - STERZO
1Vite
2 Testa di sterzo
3Ghiera
4 Anello di tenuta
5 Cuscinetto
6 Cuscinetto
7 Anello di tenuta
8 Rosetta
9 Base di sterzo
10 Vite
11 Grano
12 Dado
13 Paraspruzzi
2
6
7
8
3
4
5
9
12
13
10
1
11
2 - STEERING
1 Screw
2 Steering head
3 Ring nut
4Seal
5Bearing
6 Bearing
7Seal
8 Washer
9 Bottom yoke
10 Screw
11 Grub screw
12 Nut
13 Splashguard
Importante
I riferimenti in grassetto all’interno di questo capitolo indicano che i
particolari richiamati non sono presenti nelle immagini a fianco del testo, ma
devono essere ricercati nella presente tavola esplosa.
Caution
Bold reference numbers in this section identify parts shown in this
exploded view diagram. These parts do not appear in the figures near the
text.
