Motore
Engine
sezione / section
N 1
6
A
B
C
D
E
F
G
H
L
M
N
P
Monster 400/620 - M.Y. 2004 - edizione/edition 00
REAR BRAKE
MASTER CYLINDER
G 6
COMPLETE
MOTORCYCLE
SEAT
E 3
BATTERY
BATTERY MOUNT
P 2
EXHAUST SYSTEM
L 8
ENGINE
ELECTRICAL
CONNECTIONS
P 1
SIDE STAND
H 5
AIR-BOX
L 2
THROTTLE BODY
L 6
ENGINE-TO-FRAME
SCREWS
SWINGARM SHAFT
N 1
FUEL TANK
L 2
GEARCHANGE
CONTROL
F 5
COMPLETE
ENGINE
CLUTCH TRANSMISSION
F 2
CRANKSHAFT
SPROCKET
G 8
Removing the engine
To remove the engine, you first have
to remove other components from
the bike.
Most disassembly procedures for
these components are described in
the relevant sections.
The following diagram is a logical
disassembly sequence of the parts to
be removed and makes reference to
the relevant sections describing the
specific disassembly procedures.
This section describes only the
operations to be carried out after
having removed all the parts shown in
the diagram.
To Next Page
