Ducati monster 620 i.e. - Page 246

Mototelaio
Frame
sezione / section
H 6
18
A
B
C
D
E
F
G
H
L
M
N
P
Monster 400/620 - M.Y. 2004 - edizione/edition 00
FUEL TANK
L 2
AIR
BOX
L 7
REAR
SUSPENSION
G 7
HORN
SUPPORT
P 5
THROTTLE
BODY
L 6
OIL BREATHER
TANK
N 2
REMOVING
ENGINE
N 1
REMOVING
WIRING
UPPER
CONNECTIONS
P 1
COMPLETE
BATTERY
MOUNT
P 2
REAR
WHEEL
ASSEMBLY
G 4
REAR
BRAKE
SYSTEM
G 6
HEADLIGHT
SUPPORT
P 4
HANDLEBAR
RH/LH
CONTROLS
P 3 - P 5
FRONT
HYDRAULIC
BRAKE
F 3
REAR
HYDRAULIC
BRAKE
F 4
STEERING
UNIT,
FORK,
FRONT
WHEEL
H 2 - G 1 - G 2
REMOVING
WIRING
FRONT
CONNECTIONS
P 1
REMOVING
WIRING
REAR
CONNECTIONS
P 1
HEADLIGHT
FAIRING
E 1
HANDLEBAR
H 1
INSTRUMENT
PANEL
P 6
SEAT
E 3
EXHAUST
L 8
FRAME
GEARCHANGE
CONTROL
F 5
CLUTCH
TRANSMISSION
F 2
CRANKSHAFT
SPROCKET
G 8
REAR
SWINGARM
AND REAR
MUDGUARD
G 5
REAR
SPLASHGUARD
E 3
NUMBER PLATE
ASSEMBLY
E 3
SIDE
STAND
H 5
FOOTPEGS
H 4
COMPLETE
MOTORCYCLE
