Caratteristiche tecniche
Technical specification
sezione / section
C 1.1
9
A
B
C
D
E
F
G
H
L
M
N
P
Monster 400 - 620 Aggiornamento/Update - M.Y. 2006 - edizione/edition 00
1.1 - TECHNICAL DATA
Description
Reference Technical specifications
Vehicle dimensions Total length 2100 mm
Total width 794 mm
Total height 1058 mm
Wheelbase 1440 mm
Handlebar height - from grip to the
ground
980 mm.
Seat height 770 mm
Front footpeg height 360 mm
Rear footpeg height 490 mm
Min. ground clearance 120 mm
Dry weight in running order with no fuel 168 kg
Weight in running order Not over 390 Kg
Frame Type Chrome-molybdenum steel tube trellis frame
Steering head angle 24°
Steering angle 27°
Trail 96 mm
Front rim Light alloy, three spokes
Front rim size MT 3.50x17"
Front tyre 120/60 - ZR 17
Rear rim Light alloy, three spokes with cush drive damper
pads
Rear rim size MT 4.50x17"
Rear tyre 160/60 - ZR 17
Type of tyre Radial tubeless tyre
Front brake Hydraulic with 2 calipers
Rear brake Hydraulic with 1 caliper
Engine Type Twin-cylinder 4-stroke Otto-cycle engine
Bore 70.5 mm (400)
80 mm (620 - 620 DARK)
Stroke 51 mm (400)
61.5 mm (620 - 620 DARK)
Displacement 398 cu. cm (400)
618 cu. cm (620 - 620 DARK)
Compression ratio 10 ± 0.5:1 (400)
10.5 ± 0.5:1 (620 - 620 DARK)
Max. power at crankshaft (95/1/EC) 32 kw (43HP) at 11,000 rpm (400)
44.3 kw (60 HP) at 9,500 rpm
(620 - 620 DARK )
Max. power at crankshaft, measured on
test bench
32.4 kw (44 HP) at
10,500 rpm (400)
64.4 kw (63 HP) at
9,500 rpm (620 - 620 DARK)
Max. crankshaft torque 31.5 Nm (3.2 kgm) at 8,750 rpm (400)
53 Nm (5.4 kgm) at 6,750 rpm (620 - 620 DARK)
