MAIN COMPONENTS AND DEVICES
1
10
13
7
8
2
9
3
5
4
9
6
11
12
13
fig. 19
Location (fig. 19)
1) Tank filler plug.
2) Seat catch.
3) Hook for helmet fastening cable.
4) Passenger grab handle.
5) Side stand.
6) Rear view mirrors.
7) Rear shock absorber adjusters.
8) Fuel tank lifting rod.
9) Seat cover (not on 620DARK and 620DARK SINGLE
DISC version).
10) Fuel tank clip.
11) Catalyzer.
12) Headlight fairing (1000S only).
13) Forn fork adjuster (1000S).
