Duke 6/13 - Page 40

40
Part # Description
153164 Baffle, 6/13 porcelain
153738 Baffle, 6/13, stainless steel
153451 Baffle ASM, burner
153056 Bearing, door hinge
153093 Blower wheel, 9-3/8” x 2”
153233 Bracket, stacking
(for double sections)
153027 Burner, oven, left
153388 Burner, oven, right,assembly
153925 Buzzer, 120v
153416 Catch, door
153237 Chain & turnbuckle
assembly, door
153234 Chain, door
145274 Chain, masterlink
153211 Cord set, 120v
153285 Door, assembly, right, 65/35
153440 Door, assembly, left, 50/50,
solid
153461 Door, assembly, left, 65/35,
solid
153441 Door, assembly, right,
50/50, solid
153434 Door, assembly, left, 50/50,
w/glass
153462 Door, assembly, left, 65/35,
w/glass
153442 Door, assembly, right,
50/50, w/glass
153443 Duct, burner, assembly, deep
153444 Duct, burner, assembly,
standard
153083 Gasket, door - side (2 required)
153084 Gasket, door - top
153085 Gasket, door - bottom
153115 Grommet, silicone, temp.
bulb/probe
153432 Handle, door, assembly,
50/50 doors
153433 Handle, door, assembly,
65/35 doors
153276 Kit, conversion - NAT to LP
153771 Kit, conversion - LP to NAT
153142 Knob, (Q & V models)
153766 Knob, “X”, digital
153143 Knob, “Z”, “ZX” controller
153105 Lamp, 50 watt, 120v
147963 Lamp, socket
153801 Latch, roller assembly
153203 Light, oven ready, 120v
153981 Module, pilot spark
153035 Motor, 1/2 HP, 120v, 2-speed
Part # Description
153134 Mylar panel, “V” model, 2-button
153758 Mylar panel, “X” model
153138 Mylar panel, “Z” model,
12-button
153482 Mylar panel, “ZX” model
153139 Mylar panel, lower
153154 Orifice, burner #44, natural
- standard depth
153155 Orifice, burner #55, propane -
standard depth
153359 Orifice, burner #43, natural -
deep depth
153360 Orifice, burner #54, propane -
deep depth
153922 Pilot burner/ignitor assembly,
natural
153923 Pilot burner/ignitor assembly,
propane
153177 Probe, “X”, “Z”, “ZX” models
153230 Rack, oven (standard depth)
153231 Rack, oven (deep depth)
153229 Rack, support
153498 Relay, fan, 12V, “X” model
153776 Relay, fan, 208-240V, “X” model
153108 Rod, connecting - short
153107 Rod, connecting - long
153235 Rod, door-stop
153114 Switch, micro, door
153071 Switch, actuator, door
153119 Switch, flame
153146 Switch, interior lights (opt.)
512289 Switch, power, “ZZ” model
153144 Switch, 2-speed fan (opt.)
153460 Switch, rotary
149403 Thermostat, (Q & V models)
156255 Timer, 60 minute, 115V, 60Hz
153324 Timer, gas delay
153358 Transformer, 240/480V, 1KVA
147753 Turnbuckle
153109 Valve, dual solenoid, combo,
120V
153122 Valve, gas shutoff
153280 Valve, pilot, adjustable
153111 Valve, single solenoid, combo,
120V
153088 Window, oven door
153481 “ZX” controller
153499 “X” controller
153150 “Z” controller
DUKE MANUFACTURING CO.
2305 N. Broadway •St. Louis, MO 63102
800.735.3853 • 314.231.1130 • 314.231.5074 fax
www.dukemfg.com
9/00
