41
ITEM PART No. DESCRIPTION QTY
1 Refer pages 44 Main Frame Assembly 1
2 Refer pages 44 Drawbar Assembly (Optional) 1
3 Refer pages 69 Hectaremeter Kit (Optional -not shown) 1
4 Refer pages 59 Seeder Mechanism 32 36
5 Refer pages 54 Gearbox Final Assembly 1
6 Refer pages 62 Seedbox Assembly 1
7 Refer pages 66 Agitator Drives 2
8 Refer pages 67 Agitator Shaft Assembly (Inside Seedbox) 2
9 Refer pages 68 Footboard Arrangement 1
10 45019S M12 x 35 Class 8.8 Set Screw Z/P 8
11 45139 M12 Nyloc Nut Z/P 8
12 61136 LH Pedestal Welded Assembly 1
13 27935 Calibration Tray 2
14 Refer pages 50 Drive Pedestal Complete Assembly 1
15 45159 M12 HD Washer Z/P 8
16 61124 Crank Handle Assembly 1
17 45040 M16 x 50 Class 8.8 Bolt Z/P 4
18 45140 M16 Nyloc Nut Z/P 4
19 45160 M16 HD Washer Z/P 4
20 43697 Wheel Assembly 2
21 Refer Pages 70 Eco Seeder Disc Openers (Optional) 1
22 Refer Pages 48 Tine Assembly 16 18
23 25730 Jockey Arm Tension Spring 1
24 27888 Jockey Arm Eyebolt 1
25 45131 M12 Hex Nut Z/P 2
26 45167 M12 Spring Washer Z/P 1
Pt. No. 67392
Issue 0918
‘EcoSeeder’ Seed Drill Dual Box Complete Assy
