43
Pt. No. 67392
Issue 0918
‘EcoSeeder’ Seed Drill Single Box Complete Assy
ITEM PART No. DESCRIPTION QTY
1 Refer pages 44 Main Frame Assembly 1
2 Refer pages 44 Drawbar Assembly (Optional) 1
3 Refer pages 69 Hectaremeter Kit (Optional - not shown) 1
4 Refer pages 59 Seeder Mechanism 14 16 18
5 Refer pages 55 Gearbox Final Assembly 1
6 Refer pages 64 Seedbox Assembly 1
7 Refer pages 66 Agitator drive 1
8 Refer pages 67 Agitator Shaft Assembly (Inside Seedbox) 1
9 Refer pages 68 Footboard Arrangement 1
10 45019S M12 x 35 Class 8.8 Set Screw Z/P 6
11 45139 M12 Nyloc Nut Z/P 6
12 61140 LH Pedestal Welded Assembly 1
13 61212 Calibration Tray 14 Run 1
14 27935 Calibration Tray 16/18 Run 1
15 Refer pages 51 Drive Pedestal Complete Assembly 1
16 45159 M12 HD Flat Washer Z/P 6
17 61124 Crank Arm Assembly 1
18 45040 M16 x 50 Class 8.8 Bolt Z/P 4
19 45136 M16 Nyloc Nut Z/P 4
20 45160 M16 HD Flat Washer Z/P 4
21 43697 Wheel Assembly 2
22 Refer pages 70 Eco Seeder Disc Openers 1
23 Refer pages 48 Tine Assembly 14 16 18
24 25730 Jockey Arm Tension Spring 1
25 25723 Jockey Arm Tension Eyebolt 1
26 45131 M12 Hex Nut Z/P 2
27 45167 M12 Spring Washer Z/P 1
To Next Page
