45
Pt. No. 67392
Issue 0918
‘EcoSeeder’ Seed Drill Mainframe and Drawbar
ITEM PART No. DESCRIPTION QTY QTY
1 61102 14R Mainframe 1 1
1 27850 16R Mainframe 1 1
1 61100 18R Mainframe 1 1
2 Refer Pages 46 Hydraulic Ram 2 0
3 27986 Pivot Pin Welded Assembly 2 2
4 45040 M16 x 50 Class 8.8 Bolt Z/P 4 4
5 45140 M16 Nyloc Nut Z/P 4 4
6 45002S M10 x 25 Class 8.8 Set Screw Z/P 6 6
7 22262 Clevis Pin Assembly (Tapped) 4 4
8 45166 M10 Spring Washer Z/P 6 6
9 43395 Heavy Duty Ratchet Turnbuckle 1 2
10 45152 M10 Light Flat Washer Z/P 6 6
11 47237 7/8” x 5 1/2” UNF HT Bolt Z/P 1 1
12 45292 7/16” x 1 1/2” Lynch Pin 2 2
13 47552 1” UNF Nyloc Nut Z/P 2 0
14 47254 1” x 5” UNF HT Bolt Z/P 1 0
15 47548 7/8” UNF Nyloc Nut Z/P 1 1
16 Refer Pages 47 LH Wheel Leg Assembly 1 1
17 Refer Pages 47 RH Wheel Leg Assembly 1 1
18 27550 LH Link Support Stay 1 1
19 27551 RH Link Support Stay 1 1
20 27861 Rear Link Stay 2 2
21 27778 Top Link Spacer Assembly 1 1
22 27960 Drawbar Assembly 1 0
23 47251 1” x 3 1/2” UNF HT Bolt Z/P 1 0
24 45295 Cat 2 x 4-1/4” Clevis Pin 2 2
To Next Page
