Duncan EcoSeeder - EcoSeeder Seed Drill Single Box Drive Pedestal

51
Pt. No. 67392
Issue 0918
‘EcoSeeder’ Seed Drill Single Box Drive Pedestal
ITEM PART No. DESCRIPTION QTY
1 Refer Pages 55 Single Output Gearbox Complete Assembly 1
2 22281P Cover Plate 2
3 44992S M8 x 20 Class 8.8 Set Screw Z/P 4
4 45165 M8 Spring Washer Z/P 4
5 Refer Pages 60 Jockey Wheel Assembly 1
6 Refer Pages 60 Drive Pedestal Shaft 1
7 Refer Pages 58 Seedbox Drive Shaft 1
8 61124 Crank Handle 1
9 61129 Drive Pedestal Welded Assembly 1
10 45157 M8 HD Flat Washer Z/P 4
11 22050 Crank Adaptor Assembly 1
12 45180 M8 x 10 Socket Head Grub Screw 2
13 22294 Sprocket Key (6x6x25) 1
2
3
4
3
4
3
4
2
3
4
6
9
8
7 1
10
5
10
10
10
12
13
11
