Duncan EcoSeeder - Page 63

61
Pt. No. 67392
Issue 0918
‘EcoSeeder’ Seed Drill Jockey Drive
ITEM PART No. DESCRIPTION QTY
1 25742 38T x 1/2” P Sprocket 25mm Bore 1
2 27887 Transfer Drive Shaft 1
3 25724 13T x 1/2” P Sprocket 20mm Bore 1
4 22294 Sprocket Key (6x6x25) 3
5 27885 13T 1/2"P Sprocket 25mmBore 1
6 25744 Jockey Wheel and Axle Assembly 1
7 43036 Drive Pedestal Transfer Shaft Bearing 2
8 17127 Jockey Wheel Axle Bearing 2
9 43386 “Y” Bearing 2
10 30359 3 Bolt Bearing Housing, PF52, (2 Flanges = 1 Housing) 2
11 25726 Jockey Drive Axle Spacer 1
12 25725 Jockey Arm Pivot Spacer 2
13 25739 Jockey Axle Inner Spacer 1
14 25727 Jockey Axle Outer Spacer (Loctite in place when fitted) 1
15 25729 Jockey Arm Pivot Outer Spacer (Loctite in place when fitted) 1
16 25735 Jockey Wheel Arm 1
17 25746 Jockey Drive Swing Guard 1
18 23410 Sensor Mount Bracket Optional with Hectaremeter Kit 1
19 43403 Sensor (with locknuts) Optional with Hectaremeter Kit 1
20 43404 Magnet and Clamp Optional with Hectaremeter Kit 1
21 44951S M6 x 16 Class 8.8 Set Screw Z/P 2
22 45164 M6 Spring Washer Z/P 2
23 45156 M6 HD Flat Washer Z/P 2
24 45180 M8 x 10 Socket Head Grubscrew 4
25 45186 M10 x 12 Socket Head Grubscrew 2
26 44992S M8 x 20 Class 8.8 Set Screw Z/P 6
27 45137 M8 Nyloc Nut Z/P 6
28 45001S M10 x 20 Class 8.8 Set Screw Z/P Optional with Hectaremeter Kit 1
29 45152 M10 Light Flat Washer Z/P Optional with Hectaremeter Kit 1
30 45138 M10 Nyloc Nut Z/P Optional with Hectaremeter Kit 1
31 47625 M16 Belleville Disc Washer 1
32 45140 M16 Nyloc Nut Z/P 1
33 45151 M16 Light Flat Washer 6
34 45163 M24 H/D Flat Washer Z/P 1
