63
Pt. No. 67392
Issue 0918
‘EcoSeeder’ Seed Drill Dual Seedbox Assembly
ITEM PART No. DESCRIPTION QTY
1 61160 Dual Box Assembly 16 Run (with seeder hardware) 1
2 61164 Dual Box With Lid 16 Run (painted sheetmetal -no hardware) 1
1 61162 Dual Box Assembly 18 Run (with seeder hardware) 1
2 61165 Dual Box With Lid 18 Run (painted sheetmetal -no hardware) 1
3 27994 Lid Only 1
4 26599 Calibration Tray Bracket 4
5 27918 Box Set Mounting Bracket 2
6 Refer Page 66 Agitator Drive Assembly 2
7 Refer Page 59 Seeder Assembly 32 36
8 27942 Transfer Ecoseeder 2
9 10143 Box Quadrant Plate 1
10 10158 Box Quadrant Plate Reversed 1
11 22419 Box Shaft Connecting Sleeve 4
12 27914 Box Shaft (20mm) 2
13 27915 Flap Shaft (18mm) 2
14 60096 Front Flapshaft Handle w/assy 1
15 60098 Rear Flapshaft Handle w/assy 1
16 22568 Location Tab (Calibration Tray) 4
17 29163 Hinge Assembly 3
18 22491 Hinge Pin 3
19 27599 Hinge Pin Spring Clip 3
20 43373 Black Edge Trim (4.6m) 1
21 45019S M12 x 30 Class 8.8 Set Screw Z/P 12
22 45159SS M12 HD Flat Washer S/Steel Z/P 12
23 45139 M12 Nyloc Nut Z/P 12
24 45186 M10 x 12 Socket Head Grubscrew 4
25 45758 M6 x 16 Countersunk Posidrive Screw Z/P 4
26 45909 M6 x 20 Pan Head Machine Screw Z/P 10
27 45907 M6 x 12 Pan Head Machine Screw Z/P 8
28 45122 M6 Hex Nut Z/P 4
29 45136 M6 Nyloc Nut Z/P 22
30 45150 M6 Light Flat Washer Z/P 6
31 45158 M10 HD Flat Washer Z/P 1
32 45368 M10 Starlock Fixing Washer 2
33 22487 Latch Rod Assembly 1
