Duncan EcoSeeder - EcoSeeder Seed Drill Disc Opener Assy (Optional)

68
ITEM PART No. DESCRIPTION QTY
1 61220 Footboard 14 Run 1
1 27982 Footboard 16 & 18 Run 1
2 27978 Footboard Bracket (Single Box) 2
2 27979 Footboard Bracket (Dual Box) 2
3 61155 Footboard Step 14 & 16 Run Single Box 16 & 18 Run Dual Box 1
3 61156 Footboard Step 18 Run (Single Box) 1
4 45051 M16 x 130 Class 8.8 Bolt Z/P 4
5 45038S M16 x 40 Class 8.8 Bolt Z/P 2
6 45140 M16 Nyloc Nut Z/P 6
7 21690 Clamp Plate (Single Box) 2
8 45020 M12 x 35 Class 8.8 Bolt Z/P 4
9 45139 M12 Nyloc Nut Z/P 4
10 43902 Decal "Slippery When Wet" (Not Shown) 1
11 27893 Harrow Hitch (Optional on Single Box) 2
‘EcoSeeder’ Seed Drill Footboard Arrangement
4
Front of machine
2
11
5
9
8
6
3
1
6
7
Harrow bracket
acts as a clamp
when fitted
instead of item 7
