75
‘EcoSeeder’ Tine Harrow (Optional)
Pt. No. 67392
Issue 0918
ITEM PART No. DESCRIPTION QTY
1 61225 Tine Harrow 14 Run Bar 1 0 0
1 61224 Tine Harrow Dual Bar 0 2 or 2
1 60425 Tine Harrow Single Bar 0 1 or 1
2 60255 LH Tine 8 10 12
3 60256 RH Tine 8 10 12
4 60422P Tine Harrow Tine Bracket 16 20 24
5 60426 Tine Harrow Strut 1 1 2
6 60428 Strut Bolt Plate 1 1 2
7 60430 Swinging Arm Assembly 1 1 2
8 60435 Guiding Bar Assembly 1 1 2
9 60437 Tine Harrow Spring 1 1 2
10 60438 Guiding Bar Bush 1 1 2
11 60439 Guiding Spacer 2 2 4
12 60440 Swinging Bracket Spacer 2 2 4
13 60441 Tine Harrow Pivot Pin 1 1 2
14 45006 M10 x 45 Class 8.8 Bolt Z/P 2 2 4
15 45016 M10 x 100 Class 8.8 Bolt Z/P 16 20 24
16 45138 M10 Nyloc Nut Z/P 18 22 28
17 45050 M16 x 120 Class 8.8 Bolt Z/P 4 4 8
18 45140 M16 Nyloc Nut Z/P 4 4 8
19 45073 M20 x 130 Class 8.8 Bolt Z/P 3 3 6
20 45161 M20 HD Flat Washer Z/P 2 2 4
21 45141 M20 Nyloc Nut Z/P 3 3 6
22 43118 M8 Grease Nipple Straight 2 2 4
23 43120 M8 Grease Nipple 90° 1 1 2
24 43675 1/4" x 1-1/2" Linch Pin 1 1 2
