Dungs MPA 41 PF Series User Manual

17 … 96
16 … 96
Printed in Germany • Edition 04.18 • Nr. 271 958
Outputs
Designation Connec-
tion X
Safety-
related
Type of output Line length Electrical data
V1
Safety valve
13 x Relay contact Max. 100 m For 250000 switching cycles:
115/230 VAC / 2 A cos ϕ = 1
For 2.5 million switching cycles:
115/230 VAC / 1 A cos ϕ = 1
Minimum load 0.5 W
V2 congurable 14 x Relay contact Max. 100 m For 250000 switching cycles:
115/230 VAC / 2 A cos ϕ = 1
For 2.5 million switching cycles:
115/230 VAC / 1 A cos ϕ = 1
Minimum load 0.5 W
Ignition 15 x Relay contact Max. 100 m For 250000 switching cycles:
115/230 VAC / 1 A cos ϕ = 0,4
corresp.
115/230 VAC / 2.5 A cos ϕ = 1
For 2.5 million switching cycles:
115/230 VAC / 1 A cos ϕ = 1
Minimum load 0.5 W
Ventilation 8 - Relay contact Max. 100 m For 250000 switching cycles:
115/230 VAC / 1 A cos ϕ = 0,4
corresp.
115/230 VAC / 2.5 A cos ϕ = 1
For 2.5 million switching cycles:
115/230 VAC / 1 A cos ϕ = 1
HT function or
AUX out
Multifunction out-
put congurable
11 - Relay contact Max. 100 m 115/230 VAC / 1 A
cos ϕ = 1
Fault
Alarm
12 - Relay contact Max. 100 m 115/230 VAC / 1 A
cos ϕ = 1
FLW power 7 - For UV41 (HE) Max. 100 m 230 VAC / 10 mA *1
Technical data
*1: The ame detector is always supplied with 230 VAC, even the 115 VAC version, via the "Flame detector supply" connection 7.
The sum of the currents of all safety-related consumers must not exceed 5 A (observe the value of the fuse)
The sum of the currents of all consumers must not exceed 6.3 A (10 A).
