Installation of the MPA 41xx

Installation options for the MPA 4122 PF:

- direct screw connection of the

housing on the installation surface

using M4 screws, length min. 20 mm

Dimensions of the MPA 4122 PF

225

123

37,9

40,5

M32x1.5 - 6H

M16x1.5 - 6H

15,5 18,5 14,6

160

240 80

Printed in Germany • Edition 04.18 • Nr. 271 958
