Standard transfer area
MPA 41xx PF
Bit Input byte EB2 Description During fault
0-7
State number or error
code
Current state number or error code if there is a fault X
Bit Input byte EB3 Description During fault
0-7 Flame quality Quality of the ame via ionisation input 0
Bit Input byte EB5 Description During fault
0-7
Resettable
runtime meter
for flame and HT
Byte 1 of the 32-bit runtime meter
(unit: s)
X
Bit Input byte EB6 Description During fault
0-7
Resettable
runtime meter for
flame and HT
Byte 2 of the 32-bit runtime meter
(unit: s)
X
Bit Input byte EB7 Description During fault
0-7
Resettable
runtime meter for
flame and HT
High byte (byte 3) of the 32-bit runtime meter
(unit: s)
X
Bit Input byte EB8 Description During fault
0-7
Resettable
start counter for
flame operation
Low byte (byte 0) of the 32-bit start counter X
Bit Input byte EB9 Description During fault
0-7
Resettable
start counter for
flame operation
Byte 1 of the 32-bit start counter X
Bit Input byte EB10 Description During fault
0-7
Resettable
start counter for
flame operation
Byte 2 of the 32-bit start counter X
Bit Input byte EB11 Description During fault
0-7
Resettable
start counter for
flame operation
High byte (byte 3) of the 32-bit start counter X
Extended transfer area
MPA 41xx PF
Bit Input byte EB4 Description During fault
0-7
Resettable
runtime meter for
flame and HT
Low byte (byte 0) of the 32-bit runtime meter
(unit: s)
X
