342
c HELP Mode Function and Operation Procedures
chap.7
H-41
(1) Adjustment / specification settingHELP mode
1. Functions
(1)
Changing of platemaking start position for second
image in multiple image printing, setting of repeat
count display, selection of sorter home position
timing
2. Operation procedures
Modes H-38,H-39 and H-40 are not used.
Display Item Setting
0***
Platemaking start position
change for 2nd image in
multiple image printing
Old version position
1***
New version position
*0**
Not used
*1**
**0*
Count repeat display
Repeat display of count
**1*
No repeat display of count
***0
Selection of sorter home
position return timing
To home position after completion
of last sheet
***0
To home position when next print
run starts
1000
Initial value
- L -
****
Correction amount display
During memorization:
(1)
Changing of platemaking start position for second image
in multiple image printing, setting of repeat count display,
selection of sorter home position timing
q
Access HELP mode H-41, and press the PRINT key.
For the basic procedure for accessing HELP modes.
w
Use the [0] and [1] numeric keys to enter a 4-place binary value for
the desired correction amount. See the table below for 4-place
binary values and the corresponding correction amounts.
r
Press the STOP key. The HELP mode selection display will
reappear.
a To exit the HELP mode : Turn the power switch OFF.
a To access another HELP mode : Enter the desired mode number
using the numeric keys.
e
Press the [=] key. The correction amount will be memorized
in the battery PCB unit's EEPROM. During memorization, "-L-"
will be displayed.
Do not turn off the power before the "-L-" display has disappeared.
IMPORTANT
\See page 291
