344
c HELP Mode Function and Operation Procedures
chap.7
H-43, H-44
(1) Adjustment / specification settingHELP mode
1. Functions
H-43
0110
0110
0110
0110
0111
0111
0111
0111
1000
1000
1000
1000
1001
1001
1001
1001
H-44
0100
0101
0110
0111
0100
0101
0110
0111
0
Rank
1
2
3
4
5
6
7
1890 – 1926
Resistance( )
1927 – 1964
1965 – 2002
2003 – 2044
2045 – 2085
2086 – 2126
2127 – 2167
2168 – 2234
0100 8 2235 – 2279
0101 9 2280 – 2324
0110 10 2325 – 2369
0111 11 2370 – 2403
0100 12 2404 – 2451
0101 13 2452 – 2499
0110 14 2500 – 2547
0111 15 2548 – 2560
H-43
0101
0101
0110
0110
0111
0111
1000
1000
H-44
0101
0111
0101
0111
0100
0111
0100
0100
0
Rank
1
2
3
4
5
6
7
1890 – 1962
Resistance( )
1963 – 2038
2039 – 2117
2118 – 2199
2200 – 2285
2286 – 2373
2374 – 2465
2466 – 2560
****
¡H-43
(1) Setting of thermal head resistance ranking
(1) Setting of thermal head resistance ranking
q
Access HELP mode H-43, and press the PRINT key.
For the basic procedure for accessing HELP modes.
w
Use the [0] and [1] numeric keys to enter a 4-place binary value for
the desired correction amount. See the table below for 4-place
binary values and the corresponding correction amounts.
2. Operation procedures
\See page 291
For desccription of operation
\See page 97
¡DP-43E/S ¡DP-33E/S
H-43
1010
1011
1011
1100
1100
1101
1101
1110
H-44
0010
0000
0010
0001
0011
0001
0011
0010
0
Rank
1
2
3
4
5
6
7
2620 – 2716
Resistance( )
2717 – 2816
2817 – 2920
2921 – 3028
3029 – 3140
3141 – 3255
3256 – 3376
3377 – 3500
¡DP-31E/S
