353
c HELP Mode Function and Operation Procedures
chap.7
H-52, H-57
(1) Adjustment / specification settingHELP mode
1. Functions
H-52
00**
11**
**0*
**1*
***1
***0
***1
***0
H-57
0***
0***
1***
1***
Item
I / F auto / manual
setting
DP-10
test pattern
Line scanning
speed
Setting
Manual
Auto(standard)
Standard
DP-10 test pattern only
1.6m sec / line
2.0m sec / line(standard)
3.2m sec / line
4.0m sec / line
0000 0000 Factory setting
(1) Setting of online conditions
¡ Use H-52 to set I/F switching (auto/manual) and online platemaking mode.
¡ Use H-57 to select data transmission speed (time for scanning of 1 line) for online
platemaking.
2. Operation procedures
****
¡H-52
(1) Setting of online conditions
q
Access HELP mode H-52, and press the PRINT key.
For the basic procedure for accessing HELP modes.
w
Use the [0] and [1] numeric keys to enter a 4-place binary value for
the desired correction amount. See the table below for 4-place
binary values and the corresponding correction amounts.
\See page 291
e
Press the [=] key. The correction amount will be memorized
in the battery PCB unit's EEPROM. During memorization, "-L-"
will be displayed.
Do not turn off the power before the "-L-" display has disappeared.
IMPORTANT
- L -
During memorization:
Related HELP mode
HELP mode H-16 \See page 317
HELP mode H-53 \See page 355
