6. Slide one of the supplied propellers onto the motor shaft and tighten down firmly
the washer and nut. You may need to hold the base plate of the motor shaft to ensure
a firm fit. Once secured, screw the spinner in place as shown using the supplied
3x5mm bolt.
5. With the glue still fresh you will need to check the alignment of the vertical tail to
the wing to ensure it is straight and true. Looking from the rear of the fuselage,
check that the vertical tail is at 90 degree’s fuselage center section. If not, adjust the
vertical tail accordingly and if necessary temporarily secure in place until the glue
begins to take hold.
Note: Your propeller should already be balanced,
but it is strongly suggested that you check to confirm and if not,
that you balance before installing the prop.
90 degree
3x5mm
5
