Whenthedetailshavebeenentered,clicktheSaveDatabasebuttontoaddyournewentrytothe
ChemicalLabelingmodule’scurrentdatabase.TheSaveLabelbuttonwillexportyourcurrentlabel
designtoitsownfile,soyoucanadjustthedesignintheLabelDesignermodule.Ifyouwanttoremove
thecurrentrecordfromthedatabase,clicktheDeleteRecordbutton.
Templates, Sizes, and Settings
ToprintNFPA‐stylechemicallabelsindifferentsizes,opentheLabelSettingsmenuandselectthe
appropriatetemplatewiththedrop‐downLabelTemplatesmenu.Thedefaulttemplatesarenamedso
thatthesizeofthelabelisshownfirst(withdimensionsininches).
Inthesamemenu,youcanalsochooseafontforthetextofyourlabel,andtoggleoptionalelements
suchasPPEsymbolsandcomments.NotalltemplatesallowforPPEsymbolsand/orcommenttext.
ThismenualsoletsyouselectwhichNFPA‐stylechemicaldatabaseyouareusing,ifmorethanone
databaseisavailable.
Printing a Label
Whenyouarereadytoprint,clickthePrintSettingsbutton.Here,choosewhichlabelsyouwantto
print,andhowmanycopiesofeach.YoucanalsocheckaPrintPreviewhere.
PressingthephysicalPrintbuttononthefrontofyourKodiakwillprintonecopyofthecurrentlabel
design,usingthecurrentprintsetting.

Pipe Marking
[Thissectioninprogress.]
ThePipeMarkingmoduleusestherecommendationsoftheANSI/ASMEA13.1standardtocreatesimple
andeffectivepipelabels.


Additional Functions
Supply Status Utility
Thisutilityshowsthecurrentlyloadedsupplies,andhowmuchofeachisremaining.Clickthesupply
rollsonKodiak’smaintoolbartoopenthisutility.
Inordertoprint,Kodiakrequiresalabelstockandtwoprintingribbons.Thisutilitycanhelpyoucheck
thatsupplieshavebeencorrectlyloaded.Ifyouneedtotrimtheedgeofyourlabelstock(afterclearing
ajam,forexample)thisutilityalsooffersaTrimfunction,whichwill“print”ashort,blanklabel,andcut
itcleanly.

