DuraLabelKodiakUserGuidev0.6(Prerelease)Page7of28

 Cutter
Back View

[Imagenotfinal]
 PowerSocket
 PowerSwitch
 EthernetPort
 USB‐BPort
 BehindRemovablePanel:AdditionalUSB‐APorts(2)
Inside

[Imagesnotfinal]
 AdjustableSupplyHolders
 SupplyHolderAdjustmentTab
 FeedRollerBarandLatch
 AdjustableSupplyGuides
 SupplySensor
 PrintHeadsandLatches(2)
 RibbonCartridges(2)
