PARTS IDENTIFICATION
NOTE
Illustrations in this manual are for explanatory purposes. The actual shape of your
mini-split equipment may vary slightly.
NOTE
The installation must be performed in accordance with the required local and national
standards. The installation may be slightly different in different markets.
Drain Pipe
Refrigerant Pipes and Signal Wire
Air Outlet
Air Inlet
Screw
Air Filter
Front
Back
Valve Cover
Signal Cable,
Refrigerant Pipes,
and Drain Pipe
Wiring Terminal
Air Outlet
Air Inlets
Indoor Unit
Outdoor Unit
