Page | 60
IN-LINE TOP SHEET FILM LOADING
1. Unroll plastic so that the plastic supply is at the bottom.
2. Place roll of top sheet on the two rollers. Pull the metal bar with casters and insert the plastic between the
casters and the first roller.
3. Make sure the plastic goes down to at least the top sheet clamp and between the flappers.
4. Use the feed plastic and cut plastic buttons to feed and cut the extra plastic. By pressing both buttons at the
same time, the roll of plastic will rewind.
5. Press reset to move the top sheet to the top. Press the "top sheet on" button on the touch screen to activate
the top sheet option.
