DURKOPP ADLER 767 - Page 12

Ausgabe/Edition:
03.2007
Änderungsindex
Rev. index: 0.0
Printed in Germany
Blatt: 12 von 16
Sheet: from
–
Insert the thread through the passage of the bobbin case.
– Thread the thread underneath the cover plate into the oblong
of the bobbin case, the thread then is automatically pulled in
the bobbin thread tension spring.
Umbauanleitung für Bobbinengreifer CLB 300
Instructions for converting bobbin hook CLB 300
767-FAS-573 & 767-AE-5-73
Teile-Nr./ Part-No.:
0791 767774
