Teile-Nr./ Part-No.:
0791 767774
Ausgabe/Edition:
03.2007
Änderungsindex
Rev. index: 0.0
Printed in Germany
Blatt: 11 von 16
Sheet: from
3. Bobbin threading scheme
–
Insert the bobbin.
– Pull off some of the first thread of the new bobbin in order to
remove the first ruffles.
– Pull the thread through the cover slit.
– Insert the thread between the bottom plate and the cover,
while holding the thread fast at the backside of the bottom
plate with a finger.
– Close the cover and securely lock it, the screw 1 must be
right at the front of the oblong.
Umbauanleitung für Bobbinengreifer CLB 300
Instructions for converting bobbin hook CLB 300
767-FAS-573 & 767-AE-5-73
1
