DURKOPP ADLER 767 Instructions

Ausgabe/Edition:
03.2007
Änderungsindex
Rev. index: 0.0
Printed in Germany
Blatt: 10 von 16
Sheet: from
2.1.2 Für Klasse: 767-AE-5-73
–
Remove the slide.
–
Remove the throat plate.
– Feed dog; remove the front screw and push it to the side.
– Loosen hook fastening screws and remove the hook.
– Remove the thread-pulling knife.
– Remove the counter-knife.
– Insert the CLB-hook, tighten the fastening screws (first screw
in the direction of rotation on the flat s pot).
2.2 Checking the hook setting
For both classes: 767-FAS-573 and 767-AE-5-73
– Looping stroke; see appendix (Service instruction
chapter 4.1, p. 15).
– Needle bar height; see appendix (Service instruction
chapter 4.2, p. 16).
– Distance between hook and needle; see appendix (Service
instruction chapter 4.3, p. 17).
– Needle guard; see appendix (Service instruction
chapter 4.4, p. 18).
2.3 Assembling the components
2.3.1 Class: 767-FAS-573
– Set the feed dog and tighten the screws.
– Mount the throat plate.
– Mount the counter-knife.
– Mount the thread-pulling knife.
– Check the bobbin case lifter setting:
Bobbin case opening; see appendix ( Service instruction
chapter 6.1, p. 24).
– Insert bobbin and thread the machine; see bobbin threading
scheme.
– Insert the slide and close it.
2.3.2 Class: 767-AE-5-73
– Set the feed dog and tighten the screws.
– Mount the throat plate.
– Check the bobbin case lifter setting:
Bobbin case opening; see appendix ( Service instruction
chapter 6.1, p. 24).
– Insert bobbin and thread the machine; see bobbin threading
scheme.
–
Insert the slide and close it.
Umbauanleitung für Bobbinengreifer CLB 300
Instructions for converting bobbin hook CLB 300
767-FAS-573 & 767-AE-5-73
Teile-Nr./ Part-No.:
0791 767774
