Teile-Nr./ Part-No.:
0791 767774
Ausgabe/Edition:
03.2007
Änderungsindex
Rev. index: 0.0
Printed in Germany
Blatt: 9 von 16
Sheet: from
1. General information
A conversion to the bobbin hook CLB 300 is possible with the
class 767-FAS-573 and 767-AE-5-73.
With class 767-AE-5-73 machines, delivered before January 1st,
2007, the rigid foot 0767 220143 (01.0) must be used.
On request: Slide 0767 140143 with sight glass for thread monitoring.
1.1 Scope of delivery
Before proceeding with the conversion task:
Please make sure that you have all components of the kit.
The complete kit for the transformation of the bobbin hook with the
order no.: 0767 150754 consists of the following components:
1x Hook 0767 150754
1x Manual 0791 767774
On request:
1x Slide (with sight glass) 0767 140143
2. Conversion
Attention! Risk of injury !
Turnthemainswitchoffandremovetheplugbeforestarting
the conversion.
The transformation may only be performed by qualified
technicians.
2.1 Disassembling the components / Inserting the bobbin
2.1.1 Class: 767-FAS-573
– Remove the slide.
– Remove the counter knife.
– Remove the thread-pulling knife.
– Remove the throat plate.
– Feed dog; remove the front screw and push it to the side.
– Loosen the hook fastening screws and remove the hook.
– Insert the CLB-hook, tighten the fastening screws (first
screw in the direction of rotation on the flat s pot).
Umbauanleitung für Bobbinengreifer CLB 300
Instructions for converting bobbin hook CLB 300
767-FAS-573 & 767-AE-5-73
