DURKOPP ADLER 8700 - Page 35

No. Part No. Note Name
名称
Qty.
1 7700 70058550 NEEDLE COOLER ANK ASM.
针尖冷却油盒组件
1
2 7700 70058501 NEEDLE COOLER ANK
针尖冷却油盒体
1
3 7700 70058600 TANK COVER
针尖冷却油盒盖
1
4 7700 37002603 NEEDLE COOLER PIPE
针尖冷却毛毡供油线管
0.05
5 7700
A
M0104008DO SCREW M4×8
针尖冷却油盒螺钉 M4×8
1
6 7700 37002405 NEEDLE COOLER OIL WICK
针尖冷却毛毡供油线
0.15
7 7700 37006505 PLUG
针尖冷却座闷塞
1
8 7700
A
M0104006DO SCREW M4×6
针尖冷却座螺钉 M4×6
2
9 7700 70058709 ab NEEDLE COOLER UNIT (OVER)
三四线针尖冷却座
1
10 7700 70058808 c NEEDLE COOLER UNIT (INTER
)
五线针尖冷却座
1
11 7700 70059004 NEEDLE COOLER FELT PRESSER
针尖冷却毛毡销
1
12 7700 70059103 ab NEEDLE COOLER FELT
三四线针尖冷却毛毡
1
13 7700 70058907 c NEEDLE COOLER FELT
五线针尖冷却毛毡
1
14 7700 70059159 NEEDLE THREAD COOLER ASM.
机针线冷却组件
1
15 7700 70059279 NEEDLE THREAD COOLER ANK ASM.
机针线冷却盒组件
(1)
16 8700 87007221DA NEEDLE THREAD COOLER ANK PLUG
机针线冷却盒塞
(1)
17 7700 YX200100 NEEDLE THREAD COOLER OIL WICK
机针线冷却油线
(1)
18 7700 70059529 NEEDLE THREAD COOLER FELT
机针线冷却毛毡
(1)
19 7700 70059628 NEEDLE THREAD COOLER FELT PRESSER
机针线冷却毛毡压板
(1)
20 7700 70059727 NEEDLE THREAD COOLER ANK UNI
T
机针线冷却盒支承座
(1)
21 8700 DA0604303TN SPRING WASHER 4
机针线冷却盒支承座碟型弹簧垫圈 4
(2)
22 8700 87050426DA SCREW M4×10
机针线冷却盒支承座螺钉 M4×10
(1)
23 8700 BM0204035DN NUT M4
机针线冷却盒支承座螺母 M4
(1)
24 8700 DP0104508DN WASHER 4
机针线冷却组件垫圈 4
1
25 8700 DT0504113TN SPRING WASHER 4
机针线冷却组件弹簧垫圈 4
1
26 8700
A
M0104010DN SCREW M4×10
机针线冷却组件螺钉 M4×10
1
32
16. NEEDLE & NEEDLE THREAD COOLER ASSEMBLY 针尖和针线冷却部件
