DURKOPP ADLER 8700 - Page 7

2. FRAME ASSENBLY（2）机壳部件（2）
No. Part No. Note Name
名称
Qty.
1 8700 87000117DA SIDE COVE
R
側盖(粉末涂料)
1
2 8700 87000216DA SIDE COVER GASKE
T
側盖垫
1
3 7700 70003903 EYE GUARD COVER BASE BUSHIN
G
护目罩支架防震垫
1
4 8700 87007107DA BUSHING D PLUG
侧盖橡胶塞
1
5-1 7700 70003606 ab
EYE GUARD COVER （7704、7714）
护目罩 (7704、7714)
1
5-2 7700 70003705 c
EYE GUARD COVER （7716）
护目罩 (7716)
1
6 8700 87003517DA EYE GUARD COVER BASE
护目罩支架
1
7 7700 70000622 FEED MECHANISM COVER
送料牙架盖
1
8 7700 70000721 GASKET
送料牙架盖垫
1
9 7700 70004406 THROAT PLATE RETAINER
针板支架
1
10 7700 70000503 OIL SIGHT WINDOW
注油盖
1
11 7700 37003403 RUBBER RING 25×2.5
注油盖O型密封圈 25×2.5
1
12 8700 87000335DA UPPER COVE
R
上盖(粉末涂料)
1
13 8700 87000434DA UPPER COVER GASKET
上盖垫
1
14 8700 87008417DA BELT COVER B
带轮罩（B）
1
15 8700 87004337DA BELT COVER
带轮罩
1
16 7700 77009009DA COVER
送料调节孔盖(粉末涂料)
1
17 7700 70009108 GASKET
送料调节孔盖垫
1
18 7700 70001717 CLOTH PLATE SID COVE
R
缝台横盖
1
19 7700 37007008 RUBBER PLUG
牙架支承轴孔油塞
1
20 8700 87007107DA BUSHING D PLUG
牙架支承轴紧固螺钉孔油塞
1
21 7700 37007206 ab RUBBER PLUG
链线弯针轴孔油塞
1
22 7700 70004505
THREAD GUIDE ， LARGE
弯针小过线管
2
23 7700 70001402 HINGE PIN
弯针罩铰链轴
1
24 7700 70000800 LOOPER COVER BRACKE
T
弯针罩座
1
25 7700 70001006 LOOPER COVER STOPPE
R
弯针罩开闭限位档块
1
26 7700 70001303 PRESSER SPRING
弯针罩压簧
1
27 7700 70001501 LOOPER COVER SPRING
弯针罩簧
1
28 7700 77000929DA LOOPER COVER
弯针罩(粉末涂料)
1
29-1 7700 70005423 a THREADING DIAGRAM (7704
)
穿线图
(
7704
)
1
29-2 7700 70005522 b THREADING DIAGRAM (7714
)
穿线图
(
7714
)
1
29-3 7700 70005621 c THREADING DIAGRAM A (7716)
穿线图A 7716)
1
30 7700 77083222DA c CLOTH WASTE COVER
排屑罩
1
31 7700 77083024DA ab CLOTH WASTE COVER
排屑罩
1
32 7700 70001105 GUIDE PLATE
弯针罩导板
1
33 7700 70001204 PRESSER PLATE
弯针罩压板
1
34 8700 87003309DA CLOTH WASTE COVER ,LEFT
排屑罩（左）
1
35 7700 70002774 CLOTH PLATE COMPL.
缝台组件
1
36 7700 70002806 ECCENTRIC BUSHING
缝台偏心套
1
37 7700 DA0604303TO DISC SPRING 8×4.2×0.4×0.6
缝台铰链轴碟型弹簧垫圈 8×4.2×0.4×0.6
2
38 7700 37000003 CLOTH PLATE HINGE SHAFT COLLAR
缝台铰链轴紧圈
1
39 7700 70002905 CLOTH PLATE SPRING
缝台开闭簧
1
40 8700 87003269DA CLOTH PLATE COVER COMPL.
缝台罩组件
1
41 7700 70002004 RUBBER CUSHION
缝台罩防震垫
2
42 8700 87047108DA HINGE SCREW
缝台锁紧钩轴位螺钉
1
43 8700 87047009DA SPRING
缝台锁紧钩扭簧
1
44 8700 87046902DA LEVER
缝台锁紧钩
1
45 8700 87010804DA WASHER
缝台锁紧钩垫圈
1
46 8700
A
M0904010DN SCREW M4×10
侧盖螺钉 M4×10
6
47 8700 87015209DA SCREW M4×7.5
侧盖螺钉 M4×7.5
3
48 8700 87015308DA SCREW M4×8
护目罩支架螺钉 M4×8
1
49 8700 DB0308503TN WAVED WASHER 8.5×12.5×0.3
护目罩支架波形弹簧垫圈8.5×12.5×0.3
1
50 7700 70003804 EYE GUARD COVER BASE COLLA
R
护目罩支架衬圈
1
51 7700 37011505 WASHER 4
护目罩支架小垫圈 4
1
52 7700
A
M0103005DN SCREW M3×5
护目罩螺钉 M3×5
2
53 8700 87001001DA SCREW M3×2.5
护目罩锁紧螺钉 M3×2.5
1
54 7700
A
M0904008DO SCREW M4×8
牙架盖螺钉 M4×8
5
55 7700
A
M0804008HO SCREW M4×8
牙架盖螺钉 M4×8
1
56 7700
A
M0304004HO SET SCREW M4×4
针板支架调节螺钉 M4×4
2
57 7700 37024102 SCREW M3×8
针板支架紧固螺钉 M3×8
2
58 7700 DP0203205DO WASHER 3
针板支架垫圈 3
2
59 7700 37006802 CLOTH PLATE RUBBER CUSHION B
缝台防震垫（B）
1
60 8700 87019508DA SCREW M5×14
上盖螺钉 M5×14
8
61 8700 87026008DA SCREW 3.5×12
带轮罩（B）紧固螺钉 3.5×12
2
62 8700
A
M0905016DN SCREW M5×16
带轮罩紧固螺钉 M5×16
4
63 8700
A
M0906012DN SCREW M6×12
附属装置螺钉 M6×12
1
64 8700 DP0204308BN WASHER 4
弯针罩垫圈 4
3
65 8700
A
M0904010DN SCREW M4×10
弯针罩螺钉 M4×10
3
66 7700
A
M0904006HO SCREW M4×6
弯针罩压簧螺钉 M4×6
1
67 7700 37018005 SCREW M4×4
弯针罩压板螺钉 M4×4
1
68 8700
A
M0904008DN SCREW M4×8
排屑罩螺钉 M4×8
2
69 8700
A
M0904006DN SCREW M4×6
排屑罩（左）紧固螺钉 M4×6
2
70 7700
A
M0304004HO SET SCREW M4×4
弯针罩铰链轴螺钉 M4×4
1
71 8700
A
M0904006DN SCREW M4×6
弯针罩导板螺钉 M4×6
1
72 8700
A
M0904006DN SCREW M4×6
缝台横盖螺钉 M4×6
2
73 7700 DP0204308BO WASHER 4
缝台罩垫圈 4
3
74 7700
A
M0904006HO SCREW M4×6
缝台罩紧固螺钉 M4×6
3
75 7700
A
M0303003HO SCREW M3×3
缝台铰链轴紧圈紧固螺钉 M3×3
1
76 7700 DP0204308BO WASHER 4
缝台开闭簧垫圈 4
2
77 7700
A
M0104008DO SCREW M4×8
缝台开闭簧紧固螺钉 M4×8
2
78 7700
A
M0304006HO SCREW M4×6
缝台偏心套紧固螺钉 M4×6
1
79 7700 37007305 ab RUBBER PLUG
链线弯针进出轴孔油塞
1
80 8700
A
M0904008DN SCREW M4×8
主送料调节盖螺钉 M4×8
6
81 7700 70005720 c THREADING DIAGRAM B (7716)
穿线图B (7716)
1
82 7700
A
M0904008DO SCREW M4×8
弯针罩开闭限位挡块螺钉 M4×8
2
