L C P Min Max Preset Unity Description
Thread tension
t 09 00 0 3 2 ° Mode of the thread tension release and thread tension
reduction with active foot lifting.
0 = No thread tension release;
1 = Thread tension release in the seam;
2 = Thread tension release after thread trimming;
3 = Thread tension release in the seam and after thread
trimming.
t 09 01 0 1 1 ° Thread tension release by thread help
0 = No;
1 = Yes
t 09 02 0,0 2,55 0,0 s Delay time of the tread tension release after thread trimming.
(Only active if t 09 00 = 2 or 3)
t 09 03 0 2 0 ° Coupling thread tension with high lift walking foot
0 = No coupling;
1 = Additional thread tension when rapid stroke adjustment;
2 = Additional thread tension when reaching the high lift
walking foot speed limit;
t 09 10 0 359 225 ° on switching angle t 08 of 12 < = t of 09 10 < t 09 11 at the
trimming process
t 09 11 0 359 325 ° off switching angle t of 09 10 < t 09 of 11 < = t 08 13 at the
trimming process
t 09 20 0 255 0 ms Delay time for a repeated activation of the tension magnet at
the trimming process.
t 09 21 0 255 20 ms Delay time for turning the tension magnet off at the trimming
process
t 09 50 0 999 100 ms Drive time of the thread tension magnet in the time period t
1
t 09 51 5 100 100 % Pulse duty ratio in the time period t
1
t 09 52 0,0 600,0 60,0 s Drive time of the thread tension magnet in the time period t
2
(If you adjust 0s the thread tension magnet will be driven
permanently)
t 09 53 5 100 50 % Pulse duty ratio in the time period t
2
t 09 54 0 1 0 - Increasing U
mag
when the thread tension magnet will be driven
0 = No;
1 = Yes
High lift for walking foot
t 10 00 0 1 0 - High lift for walking foot
0 = No;
1 = Yes
t 10 01 0 9999 1800 rpm High lift walking speed
t 10 02 1 21 10 Step Lower speed break point
t 10 03 1 21 19 Step Upper speed break point
t 10 04 - - - - Show the actual position of the potentiometer and the actual
limitation of the speed
3: 2800
3: = actual position
2800 = speed limitation
t 10 06 0 1 0 - Speed limitation by rapid stroke adjustment
0 = Speed limitation on high lift walking speed for 500 ms;
1 = Permanently speed limitation on high lift walking speed;
t 10 07 0,0 2,55 0,0 s Run-out time of the high lift walking speed
t 10 08 0 255 0 Stiche Minimum number of stitches for high lift for walking foot
t 10 09 0 1 1 - Type of speed limitation potentiometer
0 = 9880 867105;
1 = 9880 867119;
