Operating manual part II
© 2013 Dürkopp Adler AG II-11
L C P Min Max Preset Unity Description
Function module
t 11 00 0 11 2 - Function of module 1 (X2.30)
0 = No Function;
1 = Additional thread tension;
2 = Switch stitch length;
3 = Single stitch with stitch length switching;
4 = Single stitch backwards with stitch length switching;
5 = Lift/lower roller;
6 = Lift/lower fabric end stop;
7 = Lift/lower edge trimmer;
8 = Switch stitch length (Triflex) with DB2000 and no
backtack;
9 = Fullness control with speed limitation DB3000;
10 = Fullness control without speed limitation DB3000;
11 = Step trimming
t 11 01 0 1 0 - Output of function module 1 (X2.30) inverted
0 = No;
1 = Yes
t 11 02 1 3 1 - State of the function module 1 (X2.30) after thread trimming
1 = Unchanged;
2 = Deactivated;
3 = Activated;
t 11 03 1 3 1 - State of the function module 1 (X2.30) after power on
1 = Unchanged;
2 = Deactivated;
3 = Activated;
t 11 30 0 11 1 - Function of module 2 (X2.20)
0 = Look at parameter t 11 00
t 11 31 0 1 0 - Output of function module 2 (X2.20) inverted
0 = No;
1 = Yes
t 11 32 1 3 1 - State of the function module 2 (X2.20) after thread trimming
1 = Unchanged;
2 = Deactivated;
3 = Activated;
t 11 33 1 3 1 - State of the function module 2 (X2.20) after power on
1 = Unchanged;
2 = Deactivated;
3 = Activated;
t 11 60 0 11 0 - Function of module 3 (X2.15)
0 = Look at parameter t 11 00
t 11 61 0 1 0 - Output of function module 3 (X2.15) inverted
0 = No;
1 = Yes
t 11 62 1 3 1 - State of the function module 3 (X2.15) after thread trimming
1 = Unchanged;
2 = Deactivated;
3 = Activated;
t 11 63 1 3 1 - State of the function module 3 (X2.15) after power on
1 = Unchanged;
2 = Deactivated;
3 = Activated;
t 11 90 0 999 100 ms Drive time of output FF3 in the time period t
1
t 11 91 5 100 100 % Pulse duty ratio in the time period t
1
t 11 92 0,0 600,0 0,0 s Drive time of output FF3 in the time period t
2
(If you adjust 0s the output FF3 will be driven permanently)
