DURKOPP ADLER DAC basic Operating Manual

Operating manual part II
II-12 © 2013 Dürkopp Adler AG
L C P Min Max Preset Unity Description
t 11 93 5 100 35 % Pulse duty ratio in the time period t
2
t 11 94 0 1 0 - Increasing U
mag
when the output FF3 will be driven
0 = No;
1 = Yes
Turning Back
t 12 00 0 1 1 - Turning back
0 = No;
1 = Yes
t 12 01 10 180 30 ° Moving angle of rotation
t 12 02 10 255 40 ms Waiting time up to the turning back
Needle cooling
t 13 00 0 1 0 - Mode of the needle cooling
0 = Normal needle cooling;
1 = Needle cooling depending on speed
t 13 01 0,0 9,999 2,500 s Switch-off delay of needle cooling
t 13 02 100 9999 2000 rpm Speed for activate the needle cooling
t 13 03 0 1 0 - Needle cooling with foot lifting
0 = No;
1 = Yes
Roller
t 14 00 0 3 0 - Mode for lifting the roller
0 = No lifting;
1 = Lifting with sewing foot;
2 = Lifting with bartack;
3 = Lifting with bartack and sewing foot
t 14 01 0 1 0 - Lifting roller when enabling high lift for walking foot.
0 = No;
1 = Yes
t 14 02 0 1 0 - Stitch counting after sewing foot lifting till roller remains
lowered. (t 14 03)
0 = No;
1 = Yes
t 14 03 0 255 0 Stitches Number of stitches till lower the roller
Edge trimmer
t 15 00 0 7 0 - Mode for automatic lifting of the edge trimmer
0 = No automatic lifting;
1 = with foot lifting;
2 = After thread trimming or after stitch counting(t 15 04);
3 = After thread trimming or after stitch counting(t 15 04) and
with foot lifting;
4 = with backtack;
5 = with backtack and foot lifting;
6 = After thread trimming or after stitch counting (t 15 04) or
with backtack;
7 = After thread trimming or after stitch counting (t 15 04) or
with backtack and with foot lifting
t 15 03 0 255 0 Stitches Number of stitches to lowering the edge trimmer.
t 15 04 0 255 0 Stitches Number of stitches to lifting the edge trimmer
(t 15 00 = 2 od. 3).
t 15 10 0 1 0 - Motor of the edge trimmer active
0 = No;
1 = Yes;
t 15 11 0 1 0 - Electrical edge trimmer motor will stop by sewing stop
0 = No;
1 = Yes;
t 15 12 0 100 50 % Minimum duty cycle of edge trimmer motor.
t 15 13 0 100 95 % Maximum duty cycle of edge trimmer motor.
