L C P Min Max Preset Unity Description
t 15 14 0 9999 1500 rpm Maximum speed for the maximum duty cycle
t 15 20 0,1 2,55 0,50 s Delay after switch off the edge trimmer for the step trimming
process
t 15 21 0,1 2,55 0,50 s Delay for move out the step trimmer
t 15 22 0,1 2,55 0,50 s Time for blowing during move out the step trimmer
t 15 23 0,1 2,55 0,50 s Delay for switch off the blower after sew stop
t 15 24 0,1 2,55 0,50 s Delay for switch on the edge trimmer after move out/in the
step trimmer.
Light barrier
t 16 00 50 9999 1000 rpm Speed for compensating stitches
t 16 01 1 3 3 - Light barrier mode
1 = Detection on seam begin
2 = Detection on seam end
3 = Detection on seam begin and seam end
t 16 02 0 1 0 - Mode for the seam begin
0 = Release seam start with light barrier;
1 = Start the seam with foot pedal switch and light barrier;
t 16 03 0 1 0 - Filter for knitted fabrics
0 = Off;
1 = On
t 16 04 0 1 0 - Light barrier sensing
0 = uncovered;
1 = covered
Electronic Hand wheel
t 17 00 0 1 0 - Electronic hand wheel active
0 = No;
1 = Yes (t 51 32 und t 51 33 = 0)
t 17 01 1 255 6 - Step for electronic hand wheel
t 17 02 0 1 0 - Direction electronic hand wheel
0 = right;
1 = left
Thread wiper
t 20 00 0 1 0 - Thread wiper
0 = Off;
1 = On
t 20 01 10 255 100 ms On Timer for thread wiper
Stitch length switching
t 30 00 0 2 2 - Speed limitation with long stitch length.
0 = Off;
1 = Speed limitation (DB2000)
2 = Speed limitation (DB3000)
t 30 01 0 2 0 - Stitch length during backtack
0 = Actual stitch length(long/normal);
1 = Normal stitch length
2 = Long stitch length
t 30 02 0 2 0 - Stitch length after thread trimming
0 = Manual chosen stitch length;
1 = Normal stitch length;
2 = Long stitch length;
Stitch length reduction
t 31 00 0 255 0 Stitches Number of stitches with stitch length reduction at seam begin.
t 31 01 0 2 1 - Stitch length reduction on thread trimming process.
0 = Off;
1 = Stitch length reduction for a hole stitch;
2 = Stitch length reduction only in the trimming process
