DURKOPP ADLER DAC basic Operating Manual

Operating manual part II
© 2013 Dürkopp Adler AG II-15
L C P Min Max Preset Unity Description
t 51 12 - - - - Hardware-Test
Bold Inputs or Outputs are only available at DACclassic
controls.
1.Analog
Um: Supply Voltage in V
U24: Supply Voltage for Outputs in V
Imo: Current of the 24V supply
PAn: Analog value of the pedal
Nre: X1.4 Analog Input
Ian: X1.1 Analog Input
I2T: I²T of the motor (Attention: Footpedal Switch and
Motor are activated!)
2.Inputs
X1.5: Manual Backtack
X1.6: Nedle up/down
X1.7: Additional thread tension (module 2)
X1.8: Switch stitch length (module 1)
X1.9: Input function module 3 (module 3)
X1.10: Limitation DB3000
X1.11: Machine run blockage
X1.12: Bobbin thread monitor
X1.13: Light barrier
X1.14: Backtack suppression/recall
X2.1: High lift for walking foot (not stored)
X2.2: High lift for walking foot (stored)
X2.3: No Function
X2.4: No Function
X2.6: No Function
X2.7: No Function
3.Outputs
X1.15: Output function module 3 (module 3)
X1.17: No Function
X1.18: Thread clamp
X1.20: Additional thread tension (module 2)
X1.21: No Function
X1.22: LED function module 3 (module 3)
X1.23: LED bobbin thread monitor left
X1.24: LED Backtack suppression/recall
X1.25: LED bobbin thread monitor right
X1.26: No Function
X1.27: No Function
X1.28: Needle cooling
X1.29: LED switch stitch length (module 1)
X1.30: Switch stitch length (module 1)
X1.31: LED additional thread tension (module 2)
X1.32: High lift for walking foot
X1.34: Backtacking
X1.35: Sewing foot lifting
X1.36: Thread tension
X1.37: Thread trimmer
t 51 13 - - - - Disturbance reports show the last on 10
t 51 14 0 1 - - Reset of the service counter
0 = No;
1 = Yes
