DURKOPP ADLER DAC basic Operating Manual

Operating manual part II
II-16 © 2013 Dürkopp Adler AG
L C P Min Max Preset Unity Description
t 51 20 0 22 3 - Function of the bartack input (machine connector Pin 5)
0 = no function;
1 = on threading help;
2 = Bartack suppression/recall;
3 = Manual bartack;
4 = Half stitch;
5 = Full stitch;
6 = Direction finder position;
7 = Turning back
8 = Input function module 1 (look at t 11 00);
9 = Input function module 2 (look at t 11 30);
10 = Input function module 3 (look at t 11 60);
11 = Needle up
12 = Ornamental Backtack;
13 = Needle cooling;
14 = Thread wiper
15 = Normal stitch length on backtack
16 = Machine run blockage (N.O.)
17 = Machine run blockage (N.C.)
18 = Switch high lift for walking foot (not stored)
19 = Switch high lift for walking foot (stored)
20 = Speed limitation (DB2000)
21 = Speed limitation (DB3000)
22 = Ligth barrier
t 51 21 0 22 2 - Function of the bartack toggle input (machine connector Pin
14)
0 = Look at parameter t 51 20
t 51 22 0 22 4 - Function of the needle up/down input (machine connector Pin
6)
0 = Look at parameter t 51 20
t 51 23 0 22 8 - Function of the input FF1 (machine connector Pin 8)
0 = Look at parameter t 51 20
t 51 24 0 22 12 - Function of the input FF2 (machine connector Pin 7)
0 = Look at parameter t 51 20
t 51 25 0 22 0 - Function of the input FF3 (machine connector Pin 9)
0 = Look at parameter t 51 20
t 51 26 0 22 0 - Function of the input DB3000 (machine connector Pin 10)
0 = Look at parameter t 51 20
t 51 27 0 22 0 - Function of the input light barrier (machine connector Pin 13)
0 = Look at parameter t 51 20
t 51 28 0 22 18 - Function of the input IN_EXT1 (additional input interface Pin
1)
0 = Look at parameter t 51 20
t 51 29 0 22 19 - Function of the input IN_EXT2 (additional input interface Pin
2)
0 = Look at parameter t 51 20
t 51 30 0 22 0 - Function of the input IN_EXT3 (additional input interface Pin
3)
0 = Look at parameter t 51 20
t 51 31 0 22 0 - Function of the input IN_EXT4 (additional input interface Pin
4)
0 = Look at parameter t 51 20
t 51 32 0 22 0 - Function of the input IN_EXT5 (additional input interface Pin
6)
0 = Look at parameter t 51 20
t 51 33 0 22 0 - Function of the input IN_EXT6 (additional input interface Pin
7)
0 = Look at parameter t 51 20
