Displacement 274 cc
Fuel Type ≥87 octane, ≤10% ethanol, unleaded gasoline
Dry Weight 41.9 lbs
Maximum Torque 12.1 ft/lb. (16.5 N·m) @ 2500 rpm
Compression Ratio 8.6:1
Bore X Stroke 75 mm x 62 mm
Engine Oil Capacity 23.67 . oz (0.7 L)
Fuel Tank Capacity 1.3 US gal. (4.92 L)
Lowest Idling Speed 1700 rpm ± 100 rpm
Dimensions LENGTH 16.4 in.
WIDTH 13.2 in.
HEIGHT 15.1 in.
Engine Type 4-Stroke OHV Forced-Air
Ignition System Non-contact transistor
Lubrication Mode Splash
Starting Type Recoil
Fuel Delivery System Carburetor
Bearing Type Stainless steel ball bearing
Shaft Rotation Counter-clockwise
Shaft Size 0.984” diameter, 2.48” long, 0.276” keyway
Shaft End M10 x 1.25 - drilled and tapped
Center of Shaft to Base 4.175”
SPECIFICATIONS
